High lift stacker, maximum load 1000 kg

lifting range 90 - 3000 mm

Lift via drawbar or foot pedal

Manual transport and lifting. Fits through most doors: wheel stops on the swivel castors ensure maximum stability even under full load.
Robust construction with reinforced mast profile. Load chain and hydraulic cylinder are located behind a guard screen for safety. Energy saving lifting via drawbar orpedal. Hardened chrome plated hydraulic ram. Progressive lowering via rubberised, ergonomically shaped drawbar handle.
Safety overload valve ensures long service life. High quality powder coating in light blue RAL 5012.

Product advantages

Lift operated via drawbar or pedal

Product & Price Information

Ref.	DT	Price / item (net)	Price / item (gross)
614 469	up to 4 weeks	2,047.00 £	2,456.40 £	Order now

Alternatives & Options

Technical data

Max. load	kg	1000
Lifting range	mm	90 - 3000
Fork length	mm	1150
Fork width	mm	172
Overall length	mm	1705
Overall width	mm	870
Loading width	mm	550
Structural height	mm	2090
Lift per pump stroke	mm	20
Design of mast		telescopic mast
Wheel fittings		2 swivel castors with wheel stops, 2 fork rollers
Steering wheel diameter	mm	150
Fork roller width	mm	60
Fork roller diameter	mm	83
Fork roller version		tandem
Steering wheel width	mm	40
Finish		powder-coated
Colour		light blue RAL 5012
