Compact lift table, static
max. load 1000 kg
Compact lift tables can be used either free standing or built-in, so that the platform is level with the ground.
The table is smoothly and quickly raised to the desired height at the touch of a button. The electro hydraulic motor is integrated into the device.
High quality powder coating, frame and platform in signal blue RAL 5005, scissor mechanism in signal orange RAL 2010.
Controlled via hand switch with 3 m cable, emergency off switch.
Operating voltage 400 V.
Control voltage 24 V.
230 V model on request.
Accessories for static compact lift tables on request.
The stationary compact lift tables are fitted with safety strips and electrically controlled safety valves which are EN-1570 compliant and fulfil VDE requirements.
Lifting capacity at full load: 3 - 4 cycles per hour in 1 shift operations
Product advantages- Low price due to high volume production
- Tested and proven for daily, 8 hour operation
- Sturdy construction
In stock
