Hydraulic lift table

max. load 1000 kg

1000 kg model

LO_QUICKLIFT

LO_BAKA

Foot operated hydraulic pump. Precise control of lowering speed. Hard chrome plated piston rod. Removable push/pull handle.
Painted melon yellow RAL 1028.
2 swivel castors, 1 with wheel stop, 2 fixed castors, ball bearings.
With integrated tool tray as standard.

Product advantages

Made in Germany

Product & Price Information

Ref.	Lifting range (mm)	Lift per pedal stroke - with load (mm)	Lift per pedal stroke - without load (mm)	Wheel diameter (mm)	Type
614 621	600 - 1270	9	26	175	QuickLift
614 619	600 - 1270	20		160	standard
614 622	700 - 1450	9	26	175	QuickLift
614 620	700 - 1450	20		160	standard

Ref.	DT	Price / item (net)	Price / item (gross)
614 621	up to 4 weeks	2,279.00 £	2,734.80 £	Order now
614 619	up to 4 weeks	2,172.00 £	2,606.40 £	Order now
614 622	up to 4 weeks	2,466.00 £	2,959.20 £	Order now
614 620	up to 4 weeks	2,549.00 £	3,058.80 £	Order now

Alternatives & Options

Technical data

Max. load	kg	1000
Platform length	mm	750
Platform width	mm	600
Overall length	mm	930
Overall width	mm	600
Colour		melon yellow RAL 1028
Finish		painted
Wheel fittings		2 fixed castors, 2 swivel castors, 1 with wheel stop
Wheel material		nylon
Wheel bearing		ball bearing
