Stair ramp, non-slip

width 815 mm

The primary function of the wheelchair ramp is to bridge stairs and high landings.
A special stamped pattern on the tread surface ensures high slip resistance and rain, snow and dirt drain off quickly through the perforations.

Start by determining the height difference to be overcome. In relation to this height difference, this results in the length of the stair ramp at an incline of 17 – 20% and the suggested order number.

Check whether the stair ramp identified is suitable for the space available.

We always recommend a stair ramp that is as long as possible. This makes the incline less steep and easier to manage.

Please contact sales to ensure your order is exact and correct.
Please specify the height difference with your order due to the production technology used.

Stair ramp, non-slip, width 815 mm

Price / item (Ex. VAT)

from £516.00

Order quantity:

{"articleNo":"M1081776","name":"Stair ramp, non-slip width 815 mm","baseProduct":"","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--000062369740_PRD_org_all.jpg"}

Versions Versions
Alternatives Alternatives
Technical data
Select item

10 of 10 items correspond to your selection criteria:

Item no. / Description of item Delivery time: Order quantity: Price / item

Item no.: 969027 49

Stair ramp, non-slip, width 815 mm, length 1505 mm

4 Week delivery

{"articleNo":"969027","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--000062369740_PRD_org_all.jpg"}

Item properties:

Length: 1,505 mm Height difference: 210 – 250 mm Weight per item: 27 kg Weight: 27 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"1505","formattedValue":"1,505"},{"name":"Height difference [mm]","normalizedName":"","value":"210 – 250","formattedValue":"210 – 250"},{"name":"Weight per item [kg]","normalizedName":"","value":"27","formattedValue":"27"},{"name":"Weight [kg]","normalizedName":"","value":"27","formattedValue":"27"}]}

Item no.: 969029 49

Stair ramp, non-slip, width 815 mm, length 1995 mm

4 Week delivery

{"articleNo":"969029","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--000062369499_PRD_org_all.jpg"}

Item properties:

Length: 1,995 mm Height difference: 295 – 345 mm Weight per item: 35 kg Weight: 35 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"1995","formattedValue":"1,995"},{"name":"Height difference [mm]","normalizedName":"","value":"295 – 345","formattedValue":"295 – 345"},{"name":"Weight per item [kg]","normalizedName":"","value":"35","formattedValue":"35"},{"name":"Weight [kg]","normalizedName":"","value":"35","formattedValue":"35"}]}

Item no.: 969030 49

Stair ramp, non-slip, width 815 mm, length 2485 mm

4 Week delivery

{"articleNo":"969030","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--000062369741_PRD_org_all.jpg"}

Item properties:

Length: 2,485 mm Height difference: 375 – 440 mm Weight per item: 43 kg Weight: 43 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"2485","formattedValue":"2,485"},{"name":"Height difference [mm]","normalizedName":"","value":"375 – 440","formattedValue":"375 – 440"},{"name":"Weight per item [kg]","normalizedName":"","value":"43","formattedValue":"43"},{"name":"Weight [kg]","normalizedName":"","value":"43","formattedValue":"43"}]}

Item no.: 969031 49

Stair ramp, non-slip, width 815 mm, length 2975 mm

4 Week delivery

{"articleNo":"969031","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--000062369742_PRD_org_all.jpg"}

Item properties:

Length: 2,975 mm Height difference: 455 – 530 mm Weight per item: 50 kg Weight: 50 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"2975","formattedValue":"2,975"},{"name":"Height difference [mm]","normalizedName":"","value":"455 – 530","formattedValue":"455 – 530"},{"name":"Weight per item [kg]","normalizedName":"","value":"50","formattedValue":"50"},{"name":"Weight [kg]","normalizedName":"","value":"50","formattedValue":"50"}]}

Item no.: 969032 49

Stair ramp, non-slip, width 815 mm, length 3500 mm

4 Week delivery

{"articleNo":"969032","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--000062369743_PRD_org_all.jpg"}

Item properties:

Length: 3,500 mm Height difference: 545 – 635 mm Weight per item: 58 kg Weight: 58 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"3500","formattedValue":"3,500"},{"name":"Height difference [mm]","normalizedName":"","value":"545 – 635","formattedValue":"545 – 635"},{"name":"Weight per item [kg]","normalizedName":"","value":"58","formattedValue":"58"},{"name":"Weight [kg]","normalizedName":"","value":"58","formattedValue":"58"}]}

Item no.: 969033 49

Stair ramp, non-slip, width 815 mm, length 3990 mm

4 Week delivery

{"articleNo":"969033","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--AA00969027II-G1.jpg"}

Item properties:

Length: 3,990 mm Height difference: 625 – 730 mm Weight per item: 66 kg Weight: 66 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"3990","formattedValue":"3,990"},{"name":"Height difference [mm]","normalizedName":"","value":"625 – 730","formattedValue":"625 – 730"},{"name":"Weight per item [kg]","normalizedName":"","value":"66","formattedValue":"66"},{"name":"Weight [kg]","normalizedName":"","value":"66","formattedValue":"66"}]}

Item no.: 969034 49

Stair ramp, non-slip, width 815 mm, length 4480 mm

4 Week delivery

{"articleNo":"969034","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--AA00969027II-G1.jpg"}

Item properties:

Length: 4,480 mm Height difference: 705 – 825 mm Weight per item: 72 kg Weight: 72 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"4480","formattedValue":"4,480"},{"name":"Height difference [mm]","normalizedName":"","value":"705 – 825","formattedValue":"705 – 825"},{"name":"Weight per item [kg]","normalizedName":"","value":"72","formattedValue":"72"},{"name":"Weight [kg]","normalizedName":"","value":"72","formattedValue":"72"}]}

Item no.: 969035 49

Stair ramp, non-slip, width 815 mm, length 5005 mm

4 Week delivery

{"articleNo":"969035","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--AA00969027II-G1.jpg"}

Item properties:

Length: 5,005 mm Height difference: 795 – 925 mm Weight per item: 80 kg Weight: 80 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"5005","formattedValue":"5,005"},{"name":"Height difference [mm]","normalizedName":"","value":"795 – 925","formattedValue":"795 – 925"},{"name":"Weight per item [kg]","normalizedName":"","value":"80","formattedValue":"80"},{"name":"Weight [kg]","normalizedName":"","value":"80","formattedValue":"80"}]}

Item no.: 969037 49

Stair ramp, non-slip, width 815 mm, length 5495 mm

4 Week delivery

{"articleNo":"969037","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--AA00969027II-G1.jpg"}

Item properties:

Length: 5,495 mm Height difference: 880 – 1020 mm Weight per item: 88 kg Weight: 88 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"5495","formattedValue":"5,495"},{"name":"Height difference [mm]","normalizedName":"","value":"880 – 1020","formattedValue":"880 – 1020"},{"name":"Weight per item [kg]","normalizedName":"","value":"88","formattedValue":"88"},{"name":"Weight [kg]","normalizedName":"","value":"88","formattedValue":"88"}]}

Item no.: 969038 49

Stair ramp, non-slip, width 815 mm, length 5985 mm

4 Week delivery

{"articleNo":"969038","name":"Stair ramp, non-slip width 815 mm","baseProduct":"M1081776","productUrl":"/p/M1081776/","imageUrl":"/Stackers_lifting_equipment/Loading_ramps/Stair_ramp_non-slip_pdpsmall--AA00969027II-G1.jpg"}

Item properties:

Length: 5,985 mm Height difference: 960 – 1115 mm Weight per item: 96 kg Weight: 96 kg

{"features":[{"name":"Length [mm]","normalizedName":"","value":"5985","formattedValue":"5,985"},{"name":"Height difference [mm]","normalizedName":"","value":"960 – 1115","formattedValue":"960 – 1115"},{"name":"Weight per item [kg]","normalizedName":"","value":"96","formattedValue":"96"},{"name":"Weight [kg]","normalizedName":"","value":"96","formattedValue":"96"}]}
