Ref.: 830955 49

Acoustic partition industry, complete modules

Acoustic partition

LxWxH 2656 x 2131 x 2000 mm

Length [mm]
Width [mm]
Height [mm]
New
£3,650.00
Price / item (Excl. VAT)
Delivery time: Over 4 weeks
Product description
  • Effective noise protection for better health and improved well being in warehouses, production areas, etc.
  • Higher productivity due to greater work focus
  • Screening of workplaces with increased noise emissions
  • Modular design enables customised solutions in straight and right angled set ups
  • Optional equipment models: window elements, door elements, acoustic sails
In working environments where there is constant background noise, effective sound insulation ensures greater concentration, precision and efficiency. Acoustic systems significantly reduce disturbances due to noise. They help prevent health risks and also help to avoid cost intensive production downtimes.
How they work:
Our acoustic panels are a robust, powder coated sheet steel construction with smooth and perforated sides. The perforated side faces the source of the sound. The smooth side prevents the noise from penetrating into the area being protected.
There is a polyester fleece between the smooth sheet and perforated sheet that absorbs and dampens the sound. The acoustic elements achieve the best effect at a frequency range between 200 and 4000 Hz.
Individual modules are easy to join together. System components of different sizes allow almost any set up in the room.
Floor anchors level out uneven flooring and reduce tripping hazards. Standard colour dust grey RAL 7037 – other colours available upon request.
Technical data
Materialsheet steel polyester fleece
Panel thickness103 mm
Colourdusty grey RAL 7037
Product typein-plant modular offices
Suppliedflat pack
Length2656 mm
Width2131 mm
Height2000 mm
Weight247.86 kg
