Ref.: 176989 49
Mini lifter, max. load 65 kg steel
(1)
height 1932 mm
Lifting range [mm]
Ref.: 176989 49
Mini lifter, max. load 65 kg steel
(1)
height 1932 mm
height 1932 mm
Lifting range [mm]
£2,850.00
Price / item (Excl. VAT)
Only 11 available
Delivery time: 7-10 Working days
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery
- Fast delivery
We will be happy to help you
01442 238000
Monday-Friday 8am-5pm
Do you have any questions about this product?£2,850.00
Price / item (Excl. VAT)
Product description
- Max. load 65 kg
- Suitable for Euro pallets, clearance height 91 mm
- Proven, durable technology
More powerful than comparable lifters and even more versatile with a lifting height of 1569 or 1819 mm. Linear lifting-lowering movement by means of a precision spindle. Soft start and stop. Electronic overload protection and safety friction clutch.
Progressively height adjustable handles.
Removable nylon platform is supplied.
Long life, robust steel/aluminium construction. Aluminium, steel parts and motor housing powder coated in sky blue RAL 5015.
Progressively height adjustable handles.
Removable nylon platform is supplied.
Long life, robust steel/aluminium construction. Aluminium, steel parts and motor housing powder coated in sky blue RAL 5015.
Available on request
Other lifting heights, ESD wheel fittings, custom made accessories and much more.
Other lifting heights, ESD wheel fittings, custom made accessories and much more.
Mini lifters
Are used where frequent lifting is required. The low weight, non-marking tyres with wheel stops and ergonomically placed handles make these lifters exceptionally manoeuvrable and versatile.
Are used where frequent lifting is required. The low weight, non-marking tyres with wheel stops and ergonomically placed handles make these lifters exceptionally manoeuvrable and versatile.
Delivered with support legs unattached – easy self-assembly.
Technical data
| Max. load | 65 kg |
|---|---|
| Load centre | 220 mm |
| Length | 816 mm |
| Width | 498 mm |
| Clearance height | 91 mm |
| Material | steel aluminium |
| Feature | electric |
| Finish | powder coated |
| Colour | sky blue RAL 5015 |
| Fittings | battery |
| Battery | 2 x 12 V / 7.2 Ah |
| Battery charger | 100 – 240 V / 1 A |
| Wheel fittings | 4 swivel castors with wheel stop |
| Castor diameter front / rear | 60 / 100 mm |
| Platform width | 498 mm |
| Platform length | 440 mm |
| Product type | mini lifters |
| Supplied | flat pack |
| Lifting range | 127 – 1569 mm |
| Height | 1932 mm |
| Weight | 40.3 kg |
| Instructions |
