Ref.: 648707 49

Compressed air drum pump set – Jessberger for flammable media, 91 l/min, 400 W

Compressed air drum pump set – Jessberger
Compressed air drum pump set – Jessberger, for flammable media, 91 l/min, 400 W, explosion protected-0
Compressed air drum pump set – Jessberger (Product illustration 2)-1
Compressed air drum pump set – Jessberger, for flammable media, 91 l/min, 400 W, explosion protected-2
Compressed air drum pump set – Jessberger (Product illustration 4)-3

explosion protected

£2,350.00
Price / item (Excl. VAT)

Delivery time: 2 Week delivery
Happy Easter
10% Easter discount* on the entire range with the code: EASTER24. Shop + save now!
Product description
Compressed air pump set for 200 litre drums.
For flammable media in explosion hazard zone 0 or for use in explosion hazard zones 1 or 2.

– No-seal version without mechanical seal
– Pump unit made of stainless steel 1.4571
– 2 m conductive multi-purpose hose 1'' (NW 25) made of crosslinked polyethylene
– 2 stainless steel hose connections with 1 1/4'' and 1'' internal threads
– 1 nickel plated brass nozzle with PTFE seals
– 1 potential equalisation cable set for earthing the drum pump

For flammable media:
Alcohol, petrol, brake cleaner, butyl acetate, antifreeze concentrate, isopropanol, kerosene, concentrated formic acid, acetic acid or propionic acid, solvents such as acetone, butanol, ethanol, methanol, toluene etc.

Stainless steel compressed air motor, 400 W at max. 6 bar operating pressure. Stainless steel housing, motor with ball cock and silencer, Ex II 2 GD c IIC (80 °C) X.
Special seals available – please ask.
  • For 200 litre drums
  • High level of safety when flammable media are used in hazardous areas
  • Low weight – easy handling
For flammable liquids
For flammable liquids
Technical data
Connection type1 1/4 inch
Pump rate91 l/min
Operating pressure min./max.max. 6 bar
Power400 kW
For mediaflammable hydrocarbons, such as ethanol, petrol, butanol, isopropanol, kerosene, methanol, petroleum
solvents (explosion protected)
for flammable media
highly flammable/flammable/high purity liquids explosion hazard zone 0
Design of pumpno-seal version without mechanical seal
Material of pumpstainless steel
Pump unit materialstainless steel / PTFE / FKM
Drive shaft materialstainless steel
Immersion depth1000 mm
Immersion tube diameter41 mm
Pumping height13 m wc
Immersion tube length1000 mm
Nominal hose diameter25
Max. viscosity at +20 °C600 mPas
Featureexplosion protected
Discharge hose length2000 mm
Product typecompressed air pumps
Suppliedpre-assembled, final assembly by customer
Weight9.77 kg
