Edmolift – Low profile lift table LxW 1500 x 800 mm, lifting range up to 800 mm, closed platform

  • Increased lift range from a shorter platform
  • No pit required
  • Lifting eyelets in the base frame for problem free transport and installation
  • Overload protection
  • Maintenance free bearings
Edmolift
With ramp (accessory) and foot operated control unit
Edmolift – Low profile lift table, LxW 1500 x 800 mm, lifting range up to 800 mm, closed platform, 400 V, with hand operated control unit
Price / items (Plus VAT)
from
£3,250.00

Product description
The newly developed, patented lifting mechanism enables an extremely low height when collapsed.
Pushing a button drives the table smoothly and quickly to the ergonomically correct height.
The hydraulic motor is in a robust, easy to transport plastic box and is connected to the table via quick connectors.
High quality powder coating, frame and platform in ultramarine blue RAL 5002, scissor mechanism in signal orange RAL 2010.
Supplied complete with control unit. With emergency off switch. Control voltage 24 V, 3 m long cable.
All lift tables are fitted with safety rails and safety valves, and comply with EN 1570-1 as well as VDE requirements.
Alternative models available on request.

Other max. loads up to 2000 kg available in the webshop.
  • Increased lift range from a shorter platform
  • No pit required
  • Lifting eyelets in the base frame for problem free transport and installation
  • Overload protection
  • Maintenance free bearings
Technical data
Max. load1000 kg
Lifting range80 – 800 mm
Platform designclosed
Lifting time13 sec
Control voltage24 V
Platform colourultramarine blue RAL 5002
Scissor mechanism coloursignal orange RAL 2010
Finishpowder coated
Frame colourultramarine blue RAL 5002
Product typelow profile lift table
Lifting capacity at full load in multiple-shift operations3 – 4 cycles per hour
Platform width800 mm
Platform length1500 mm
Featurestationary
electro-hydraulic
Suppliedflat pack
