Ref.: 499838 49
Trailer – eurokraft pro 4-wheel linked ackerman steering, max. load 8 t
platform 2.5 x 1.25 m, light blue
Platform length [mm]
Platform width [mm]
Loading height [mm]
Colour
Ref.: 499838 49
Trailer – eurokraft pro 4-wheel linked ackerman steering, max. load 8 t
platform 2.5 x 1.25 m, light blue
platform 2.5 x 1.25 m, light blue
10 year guarantee
Sustainability score:Platform length [mm]
Platform width [mm]
Loading height [mm]
Colour
£8,490.00
Price / item (Excl. VAT)
Delivery time: Over 4 weeks
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery
- Efficient order processes for business customers
£8,490.00
Price / item (Excl. VAT)
£8,490.00
Price / item (Excl. VAT)
Delivery time: Over 4 weeks
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery
- Efficient order processes for business customers
Product description
- Impregnated wooden platform for weather resistant and non-destructive load support
- Small turning circle – steering radius 45°
- Robust welded steel construction
- Detachable drawbar, trailer coupling on both sides
- Low maintenance
- Precision tracking stability
- Durable
- Track rods and steering rods with maintenance free ball heads
- In line with workplace safety regulations for transport vehicles
Frame construction with rounded corners. Pipe corners for attaching posts or side panels, or as tie-down eyes.
Max. load up to 5 tonnes. Towing eyelet Ø 35 mm, 40 mm for 8 tonnes or more. Wheels with double ball bearings.
Practical triangular drawbar, height adjustable, with fall arrest. Extremely small turning radius – steering radius 40°.
Max. load up to 5 tonnes. Towing eyelet Ø 35 mm, 40 mm for 8 tonnes or more. Wheels with double ball bearings.
Practical triangular drawbar, height adjustable, with fall arrest. Extremely small turning radius – steering radius 40°.
Parking brake, rubber axle and lead spring, CSE tyres, side walls and other accessories available on request.
The technical specifications for these trailers makes it necessary to manufacture them to order – no right of return.
Technical data
| Max. load at 6 km/h | 8 t |
|---|---|
| Steering | all-wheel axle knuckle |
| Platform material | coniferous wood |
| Feature | detachable drawbar |
| Wheel type | solid rubber tyres |
| Wheel width | 150 mm |
| Wheel diameter | 425 mm |
| Steering radius | 45 ° |
| Towing eyelet diameter | 40 mm |
| Product type | industrial trailers |
| Supplied | assembled |
| Platform length | 2500 mm |
| Platform width | 1250 mm |
| Loading height | 655 mm |
| Colour | light blue RAL 5012 |
| Weight | 760 kg |
| Manufacturer / EU responsible Person (GPSR) |
Sustainability
Sustainable product
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
Product CO₂ footprint
- LCA functional unit
- 1
- Recycled content in %?
- 50
- CO2 footprint year of calculation
- 2026
- LCA validity (in years)
- 1
- CO2 footprint calculation method product
- Calculated by our partner GlobalChanger (GreenZero) in accordance with ISO 14044 (LCA) / 14067 (PCF) (GWP100 [IPCC version]) principles.<br/>PCF values are product specific averages that have not been verified by third parties and may evolve as the data basis improves.
- CO2 footprint system boundaries
- Cradle-to-gate
PCF Lifecycle Breakdown
PCF Lifecycle Breakdown2,726kg CO₂e
| LCA Raw Material Extraction & Processing | 33.2% |
| LCA packaging production | 2.1% |
| LCA Product Manufacturing | 53.9% |
| LCA Inbound and Outbound Transportation | 10.8% |
Scoring System
More about our sustainability approach.
3.2/5.9Overall score
| Criteria | Weighting | Score |
|---|---|---|
 Climate protection | 30% | 2.5 |
 Circulatory economy | 30% | 4.6 |
 Biodiversity | 25% | 1.0 |
 Economic efficiency | 10% | 3.5 |
 Innovation | 5% | 3.9 |
