Ref.: 756363 49

Capitan 2500 stationary davit crane – Thern stationary

Capitan 2500 stationary davit crane – Thern
Capitan 2500 stationary davit crane – Thern, stationary, max. load 1270 kg-0
Capitan 2500 stationary davit crane – Thern (Product illustration 2)-1

max. load 1270 kg

£13,700.00
Price / item (Excl. VAT)
Delivery time: 4 Week delivery
Product description
  • Large range
  • Swivels 360°
Telescopic crane arm with 4 easily adjustable operating positions. Adjustable crane arm angle adjustable by means of ratchet tensioner. Robust and suitable for stationary use in demanding environments. Supplied complete with: crane with painted base, manual wire rope winch with zinc plated spur gear transmission, stainless steel rope with load hook, Ø 9.5 mm, length 13.5 m. Without a set of bolts for mounting (see Accessories).
Technical data
Max. load1270 kg
Max. load (at jib length mm)1346 mm – 1270 kg, 1625 mm – 1180 kg, 1905 mm – 1000 kg, 2209 mm – 860 kg
Width3098 mm
Height3810 mm
Length3098 mm
Lifting height max. cantilever arm extended3810 mm
Max. crane arm length3098 mm
Min. crane arm length1346 mm
Finishpainted
Max. hook height with max. crane arm angle3810 mm
Max. hook height with min. crane arm angle1825 mm
Weight291 kg
Product typeslewing cranes
Suppliedpre-assembled, final assembly by customer
