Ref.: 945581 49
Boltless shelving unit – eurokraft pro single row
(23)
shelf WxD 1000 x 400 mm, blue, height 2000 mm, extension shelf unit
Shelf unit type
Number of shelves [pcs.]
Shelf depth [mm]
Shelf unit height [mm]
Overall width [mm]
Colour of uprights
Ref.: 945581 49
Boltless shelving unit – eurokraft pro single row
(23)
shelf WxD 1000 x 400 mm, blue, height 2000 mm, extension shelf unit
shelf WxD 1000 x 400 mm, blue, height 2000 mm, extension shelf unit
£265.00
Price / item (Excl. VAT)
Delivery time: 2 Week delivery
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery
- Fast delivery
We will be happy to help you
01442 238000
Monday-Friday 8am-5pm
Product description
- Steel shelving in high quality workmanship with maximum stability
- Quick to assemble and upgrade, no tools required
- Standard and extension elements can be combined
- Various widths, heights and shelf depths available
- With RAL-RG 614 label
- Ideal for storage, workshop, business, cellar and much more
- Wide range of accessories: zinc plated rear and side panels, shelf dividers, plinth cover plates and wall fasteners
Particularly stable and high quality boltless shelving unit with RAL-RG 614 quality label for the highest load bearing capacity. The robust metal shelving unit is ideal for use in warehouses, cellars, workshops, depots, mailing rooms or archives. Frames and shelves can be assembled in a flash and without screws or tools. The cross braces are also easy to align using tension locks. Combine standard and extension elements to suit space requirements, vary the number of shelves and upright colour, and configure the shelf depth, width and height of your personal shelving unit.
Product details:
T-profile upright frame
Including clamp bases made of steel for securing to the floor, bolts and plugs not included.
Cross brace (zinc plated)
Included with delivery. Required for every standard shelf unit and for every second extension shelf unit.
Zinc plated shelves
Maximum stability due to box profile. Shelves at front and rear with 50 mm spacing and perforations for securing shelf dividers (accessory). Shelf edge height: 25 mm. Shelf height adjustment grid 25 mm.
Max. number of shelf dividers per shelf level
17 items for 1000 mm shelf width.
Product details:
T-profile upright frame
Including clamp bases made of steel for securing to the floor, bolts and plugs not included.
Cross brace (zinc plated)
Included with delivery. Required for every standard shelf unit and for every second extension shelf unit.
Zinc plated shelves
Maximum stability due to box profile. Shelves at front and rear with 50 mm spacing and perforations for securing shelf dividers (accessory). Shelf edge height: 25 mm. Shelf height adjustment grid 25 mm.
Max. number of shelf dividers per shelf level
17 items for 1000 mm shelf width.
Max. number of shelf dividers per shelf level
17 items for 1000 mm shelf width.
17 items for 1000 mm shelf width.
External dimensions:
Width
Standard shelf unit + 60 mm
Extension shelf unit + 6 mm
Depth
Shelf depth + 36 mm.
Max. bay load
2000 mm max. 1300 kg
2500 mm max. 1700 kg
If the height of the shelf unit equals more than 5 times its depth, it must be secured against tipping with suitable floor or wall fasteners.
Width
Standard shelf unit + 60 mm
Extension shelf unit + 6 mm
Depth
Shelf depth + 36 mm.
Max. bay load
2000 mm max. 1300 kg
2500 mm max. 1700 kg
If the height of the shelf unit equals more than 5 times its depth, it must be secured against tipping with suitable floor or wall fasteners.
The specified max. load values are applicable with uniform load distribution. Additional shelf levels may be used if the specified max. bay load is observed.
10 year guarantee
RAL quality seal: quality and inspection requirements for warehouse and workshop equipment (RAL-RG 614) defines recognised quality requirements
Technical data
Max. shelf load | 150 kg |
---|---|
Design | plug in |
Shelf height adjustment increments | 25 mm |
Shelf material | sheet steel, galvanised |
Shelf unit design | single sided |
Shelf height | 25 mm |
Product type | boltless shelving units |
Supplied | flat pack |
Shelf unit type | extension unit |
Number of shelves | 5 pcs. |
Shelf depth | 400 mm |
Shelf unit height | 2000 mm |
Overall width | 1006 mm |
Colour of uprights | gentian blue RAL 5010 |
Shelf width | 1000 mm |
Overall depth | 436 mm |
Material | steel, powder coated |
Weight | 21.02 kg |
Instructions |
